STATIC  20 |- Versatile PIC development PCB with multiple device options
STATIC-20  is a compact and versatile PIC development PCB, economized for size and portability. Supplied with a PIC18F14K22, the PCB delivers an efficient and effective development experience. The PCB includes USB UART (useful for bootcloading), ICSP header and all IO tracked to headers.

Specifications STATIC-20
DC Jack YES
USB Powered Capable YES
Device Programming ICSP
5V0 LDO Regulator YES
Package 20 PIN SOIC, pre-populated
LED | Reset Button YES
Headers Ported IO PORTs  tracked
USB UART MCP2221 Windows OS Driver support
Price See online store for current pricing
Purchase
All currency in ZAR, South African Rands



STATIC-20,- what is it?
STATIC-20 is a PIC Microcontroller development platform that allows the avid hobbiyst and professioal user to build applications. The PCB is designed to host the 44 PIN TQFP Package. This family of PIC devices is highly capable with many on board peripherals, digital IO, A2D, Serial coms, etc
Features . . .

  •  PSU : 5v0
  • USB-UART, self powered
  • Reset button
  • Power LED
  • All IO tracked to headers
  • ICSP header
Capabilities
STATIC-20 is designed with future requirements in mind. The compact design supports low power applications, has selectable COMPORT, and selectable voltage.
Deploy Applications
Embedded applications range from standalone systems which control a single element, to wired or wireless applications interconnected for reporting and monitoring. STATIC-20 is an ideal, cost effective and well supported tool with an efficient tool chain that will assist in completing projects and getting products to market.
